B-Line

75BFL2214/12

Boost productivity. Philips B-Line seamlessly integrates into corporate systems for efficient control. Chromecast built-in ensures that presentations run smoothly with instant wireless media sharing from Windows, Apple and Android™ devices.

Get a quote

Technical Specifications

Design

Colour	Anthracite Grey

Audio

External speaker out	1.5 W Mono 8 Ohm
Sound output Power	20 (2x10) W
Speakers	2.0
	Down Firing
Sound Features	DTS-HD
	Dolby Atmos Compatible
	Dolby MS12D
	AC-4
	DTS Studio Sound

Accessories

Included	Remote Control 22AV1905A/12
	2 x AAA batteries
	Power Cord
	RJ48 to DB9 adapter
Optional	Setup RC 22AV9574A/12

Corporate Features

Customisable	Home Screen
	Location Name
	Device Name
Signage Functions	CMND&Create
	Scheduler
	Banners
Control	Crestron Connected (v2)
	Extron
	Neets
	SICP over IP
Wired Presentations	Auto Input Selection
	Auto Power ON
	Auto Power OFF
Wireless Presentations	Chromecast built in
	Secure Sharing
	Network-managed Sharing

Professional TV Features

Control	CMND IP Remote Management
	JEDI Android API Control
	JAPIT HTML5 Control
	AppControl
Safety	Double Isolation Class II
	Flame Retardant
Convenience	Google Assistant*
	Google Account Login
	>40 Supported Menu Languages
	Weather Forecast
Professional Mode	Switch-ON Settings Control
	Installation Menu Lock
	Menu Lock
	Volume Limitation

Tuner/Reception/Transmission

Analogue TV	PAL
IP Playback	Multicast
	Unicast
	HLS
	OTT App Channels
Digital TV	DVB-T/T2/C
	HEVC UHD (up to 2160p60)

Wireless Connectivity

Wireless LAN	802.11 ac
	Wi-Fi-Direct

Connectivity Bottom

External power	12 V, max 1.5 A
HDMI 2	HDMI 2.0 with HDCP 2.2
Antenna	IEC-75
External speaker out	Mini-Jack
HDMI 3	HDMI 2.0 with HDCP 2.2
External Control	RJ-48
USB 2	USB 2.0
Ethernet (LAN)	RJ-45

Power

Ambient temperature	0 °C to 40 °C
EPREL registration number	935932
Energy Label Class	E
Power Saving Features	Eco mode
	Auto switch-off timer
	Light sensor
EU Energy Label power	105 W
Standby power consumption	<0.3W
Mains power	AC 220-240 V; 50-60 Hz

Dimensions

Set Depth	68/83 mm
Wall-mount compatible	M8
	300 x 300 mm
Set Height	960 mm
Set Width	1670 mm
Product weight	32.3 kg

Supported Display Resolution

HDMI	Up to 3840 x 2160p@60 Hz
USB, LAN	HEVC: up to 3840 x 2160@60 Hz
	Others: up to 1920 x 1080p@60 Hz
Tuner	T2 HEVC: up to 3840 x 2160@60 Hz
	Others: up to 1920 x 1080p@60 Hz

Picture/Display

Diagonal screen size (metric)	189 cm
Panel resolution	3840 x 2160p
Display	4K Ultra HD LED
Brightness	400 cd/m²
Operation Mode	Landscape
	16/7
Contrast ratio (typical)	1200:1
Diagonal screen size (inch)	75 inch

Side Connectivity

Headphone out	Mini-Jack
Common Interface Slot	CI+ 1.3.2
USB1	USB 3.0
HDMI1	HDMI 2.0 with HDCP 2.2

Android TV

OS	Android TV™ 9 (Pie)
Memory size (Flash)	16 GB*
Pre-installed apps	YouTube
	Google Play Store*
	Google Play Movies
	Google Play Games
	YouTube Music

Multimedia

Video playback supported	Formats: H.264/MPEG4 AVC
	MPEG1
	MPEG2
	MPEG4
	WMV9/VC1
	HEVC
	Containers: AVI, MKV
	VP9
Subtitle formats supported	SRT
	SMI
	TXT
Music formats supported	MP3
	AAC
	WAV
	WMA (v2 up to v9.2)
	WMA-PRO (v9 and v10)
Picture formats supported	JPG
	PNG
	BMP
	GIF

Connectivity Enhancements

HDMI	ARC (all ports)
	Auto Input Selection
EasyLink (HDMI CEC)	One touch play
	System Standby
	RC pass through
	system audio control
RJ48	IR-In/Out
	Serial Xpress interface
