Q-Line

55BDL3650Q/00

Inform and enthral with a Philips Q-Line 4K Ultra HD digital display. This reliable, easy-to-install, Android-powered signage solution is Wave-ready for remote management, putting you in full control, any time, anywhere.

Get a quote

Technical Specifications

Connectivity

Audio output	3.5 mm jack
Video input	HDMI 2.0 (x 2)
	USB 2.0 (x 2)
	DVI-I (x 1)
	USB 3.0 (x1)
Other connections	micro SD
External control	RJ45
	RS232C (in/out) 2.5 mm jack
	IR (in/out) 3.5 mm jack
Audio input	3.5 mm jack

Convenience

Remote control signal	Lockable
Placement	Landscape (18/7)
	Portrait (18/7)
Energy-saving functions	Smart Power
Network controllable	RS232
	RJ45
Tiled Matrix	Up to 3 x 3
Keyboard control	Lockable
	Hidden
Signal loop through	RS232
	IR Loop through

Accessories

Included Accessories	IR sensor cable (1.8 m) (x 1)
	RS232 daisy-chain cable
	Philips logo (x 1)
	AC Power Cord
	AC Switch Cover
	Quick start guide
	Remote control and AAA batteries
	RS232 cable
	USB cover and screws
	Wire Clamper (x 3)

Internal Player

Memory	16 GB
	3 GB DDR
CPU	Quad-Core Cortex A55
GPU	G52 MC1

Dimensions

Set Height	712.6 mm
Wall Mount	400 mm x 400 mm, M6
Set Width	1241.8 mm
Set Depth	63.6 mm
Set Width (inch)	48.89 inch
Product weight	16.6 kg
Product weight (lb)	36.60 lb
Set Height (inch)	28.06 inch
Set Depth (inch)	2.50 inch
Bezel width	13.9 mm (Even bezel)

Sound

Built-in speakers	2 x 10 W RMS

Power

Energy Label Class	G
Power Saving Features	Smart Power
Consumption (Typical)	111 W
Standby power consumption	<0.5 W
Mains power	100 ~ 240 VAC

Multimedia Applications

USB Playback Video	MPEG
	H.264
	H.263
	H.265
	AVI
	MP4
	VP8
USB Playback Picture	JPEG
	BMP
	PNG
USB Playback Audio	AAC
	HEAAC
	MPEG

Miscellaneous

On-Screen Display Languages	English
	French
	German
	Italian
	Polish
	Turkish
	Russian
	Simplified Chinese
	Spanish
	Traditional Chinese
	Arabic
	Japanese
Regulatory approvals	CE
	CB
	FCC, Class A
	VCCI
	RoHS
	UL
Warranty	3 year warranty

Operating conditions

Temperature range (storage)	-20 ~ 60 °C
Temperature range (operation)	0 ~ 40 °C
Altitude	0 ~ 3000 m
Humidity range (operation)[RH]	20~80% RH (No condensation)
Humidity range (storage) [RH]	5~95% RH (No condensation)
MTBF	50,000 hour(s)

Picture/Display

Panel resolution	3840 x 2160
Diagonal screen size (metric)	138.7 cm
Brightness	400 cd/m²
Pixel pitch	0.315 x 0.315 mm
Optimum resolution	3840 x 2160 @ 60 Hz
Picture enhancement	3/2 - 2/2 motion pull down
	Dynamic contrast enhancement
	Progressive scan
Display colours	1.07 Billion
Viewing angle (horizontal)	178 degree
Dynamic contrast ratio	500,000:1
Aspect ratio	16:9
Panel technology	ADS
Operating system	Android 10
Response time (typical)	9 ms
Haze	2%
Diagonal screen size (inch)	54.6 inch
Viewing angle (vertical)	178 degree
Contrast ratio (typical)	1300:1

Supported Display Resolution

Video formats	1080p, 50, 60 Hz
	1080i, 50, 60 Hz
	720p, 50,60 Hz
	2160p, 50, 60 Hz
Computer formats	1920 x 1080, 60 Hz
	1600 x 1200, 60 Hz
	1440 x 900, 60 Hz
	1280 x 1024, 60 Hz
	1280 x 720, 60 Hz
	1280 x 800, 60 Hz
	1024 x 768, 60, 70, 75 Hz
	1680 x 1050, 60 Hz
	3840 x 2160, 60 Hz
