Technical Specifications
Design
Colour | Black |
---|
Audio
Speakers | 2.0 |
---|---|
Down Firing | |
Sound output Power | 20 (2x10) W |
Sound Features | DTS-HD |
Dolby Atmos Compatible | |
Dolby MS12D | |
AC-4 | |
DTS Studio Sound | |
External speaker out | 1.5W Mono 8 Ohm |
Green Specifications
Energy Star | Yes |
---|
Accessories
Included | Remote Control 22AV1905A/12 |
---|---|
2x AAA batteries | |
Power Cord | |
Optional | Setup RC 22AV9574A/12 |
Corporate Features
Control | Crestron Connected (v2) |
---|---|
Extron | |
SICP over IP | |
Wired Presentations | Auto Input Selection |
Auto Power ON | |
Auto Power OFF | |
Signage Functions | CMND&Create |
Scheduler | |
Banners | |
Customizable | Home Screen |
Location Name | |
Device Name | |
Wireless Presentations | Chromecast built-in |
Secure Sharing | |
Network-managed Sharing |
Professional TV Features
Convenience | >40 Supported Menu Languages |
---|---|
Google Account Login | |
Google Assistant* | |
Weather Forecast | |
Control | AppControl |
CMND IP Remote Management | |
JAPIT HTML5 Control | |
JEDI Android API Control | |
DRM | Pro:Idiom |
VSecure | |
Professional Mode | Installation Menu Lock |
Menu Lock | |
Switch-ON Settings Control | |
Volume Limitation | |
Safety | Double Isolation Class II |
Flame Retardant |
Wireless Connectivity
Wireless LAN | 802.11 ac |
---|---|
Wifi-Direct |
Tuner/Reception/Transmission
Analog TV | NTSC |
---|---|
Digital TV | 8VSB ATSC; 256QAM Cable |
IP Playback | Multicast |
Unicast | |
HLS | |
OTT App Channels |
Connectivity Bottom
HDMI3 | HDMI 2.0 with HDCP 2.2 |
---|---|
HDMI4 | HDMI 2.0 with HDCP 2.2 |
Ethernet (LAN) | RJ-45 |
External power | 12V, max 1.5A |
Digital Audio out | Optical |
External speaker out | Mini-Jack |
Antenna | F-Type |
USB2 | USB 2.0 |
Power
Ambient temperature | 0°C to 40°C (32°F to 104°F) |
---|---|
Power Saving Features | Eco mode |
Auto switch-off timer | |
Mains power | AC 110-240V; 50-60Hz |
Standby power consumption | <0.5 W |
Maximum Power Consumption | 165 W |
Dimensions
Product weight (lb) | 25.4 lb |
---|---|
Set Height (inch) | 28.02 |
Wall mount compatible | 200 x 200 mm |
M6 | |
Set Depth (inch) | 3.32 |
Set Width (inch) | 48.30 |
Supported Display Resolution
HDMI | Up to 3840x2160p@60Hz |
---|---|
USB, LAN | HEVC: up to 3840x2160@60Hz |
Others: up to 1920x1080p@60Hz |
Picture/Display
Brightness | 300 nit |
---|---|
Operation Mode | Landscape |
16/7 | |
Display | 4K Ultra HD LED |
Panel resolution | 3840x2160p |
Diagonal screen size (inch) | 55 |
Contrast ratio (typical) | 1200:1 |
Android TV
OS | Android TV™ 9 (Pie) |
---|---|
Memory size(Flash) | 16GB* |
Pre-installed apps | YouTube |
Google Play Store* | |
Google Play Movies | |
Google Play Games | |
YouTube Music |
Connectivity Side
Headphone out | Mini-Jack |
---|---|
HDMI1 | HDMI 2.0 with HDCP 2.2 |
USB1 | USB 3.0 |
HDMI2 | HDMI 2.0 with HDCP 2.2 |
Multimedia
Video playback supported | Formats: H.264/MPEG4 AVC |
---|---|
MPEG1 | |
MPEG2 | |
MPEG4 | |
WMV9/VC1 | |
HEVC | |
Containers: AVI, MKV | |
VP9 | |
Subtitle formats supported | SRT |
SMI | |
TXT | |
Picture formats supported | JPG |
PNG | |
BMP | |
GIF | |
Music formats supported | MP3 |
AAC | |
WAV | |
WMA (v2 up to v9.2) | |
WMA-PRO (v9 and v10) |
Connectivity Enhancements
HDMI | ARC (all ports) |
---|---|
Auto Input Selection | |
EasyLink (HDMI CEC) | One touch play |
System Standby | |
RC pass through | |
system audio control |
