Technical Specifications
Connectivity
Other connections | micro SD |
---|---|
micro USB | |
USB, type A | |
WiFi | Wifi 2,4GHz and 5GHz |
Audio output | Speaker output (earphone jack) |
Convenience
Battery bay | 4pcs 18650 batteries (>2600mAh) not included |
---|---|
Network controllable | LAN (RJ45) |
Placement | Landscape (24/7) |
Portrait (24/7) |
Accessories
Included Accessories | AC power adapter |
---|---|
Quick start guide (x1) |
Dimensions
Set Height | 357.4 mm |
---|---|
Product weight | 2.4 kg |
Set Width | 602.4 mm |
Wall Mount | 100 x 100 mm |
Set Depth | 37.5 mm |
Internal Player
Storage | 16GB EMMC |
---|---|
Memory | 2GB LPDDR3 |
CPU | Rockchip PX30 |
Power
Mains power | 20V/2.25A adapter |
---|
Communication
Ethernet | 10M/100M |
---|---|
Wi-Fi/ WLAN | WiFi 2.4G(802.11 b/g/n) + 5GHz |
Miscellaneous
Warranty | 3 year warranty |
---|---|
Regulatory approvals | CE |
FCC |
Operating conditions
Relative humidity | 30 ~ 80 % |
---|---|
Altitude | 0 ~ 3000 m |
Temperature range (storage) | -25 ~ 50 °C |
Temperature range (operation) | 15° ~ 35° °C |
Picture/Display
Response time (typical) | 36 sec to update image |
---|---|
Operating system | Android 11 |
Aspect ratio | 16:9 |
Diagonal screen size (inch) | 25.3 |
Panel resolution | 3200 x 1800 |
Display colors | 60 000 |
