Made for results
L-Line
Unleash your imagination
Active Health Monitoring
Achieve perfection through precision. Active Health Monitoring makes maintenance fast and simple by displaying the exact location should it experience a failure. Utilising this real-time software, replacing the relevant part becomes an efficient procedure.
Factory calibrated
Calibrated in our factory under perfect conditions, Philips direct view LED installations are more efficient, with no need for on-site calibration. For fast and effective maintenance, all configuration files are available online.
Dynamic Panel Connect
Mix and match panel sizes to form a single LED wall of any shape and size. Dynamic flexible alignment ensures a perfect fit and a smooth, seamless surface. For added efficiency, each panel features openings on either side for versatile wired connections between panels and any external input connection.
Built-in cable and data wiring
Your Philips professional LED Display features built-in cable wiring to keep power and data cables tidy. Display cabinets are daisy-chained for both power and data, allowing you to minimise clutter and speed up installation.
High performance displays
Achieve perfection through precision. Quality and performance go hand-in-hand with Philips professional displays designed, manufactured, calibrated and thoroughly tested in-house.
IP30 rated conformal coating
Dust, dirt, fungus and moisture resistant conformal coating protects this product and enables easier maintenance. IP30 rated and certified against ingress for reduced chance of short circuit from dust and corrosion.
Optional easy-mount brackets
Patented easy-mount brackets make installation even faster. These optional items are available for flat LED mounting, convex curved (177.5/175/172.5 degree), and L-shape 90 degree corners.
Unique in every way
Go with the flow with a modular Philips LED display that can adapt to any shape, size or resolution. Build vast installations or assemble intriguing patterns. Flex seamlessly around doorways and openings, and move elegantly through corners and curves.
Certified fire retardancy
Fire retardant design slows down the spread of flames in the event of fire. Tested and certified with British standard (BS476), B1 DIN4102, and UL94.
Active Health Monitoring
Achieve perfection through precision. Active Health Monitoring makes maintenance fast and simple by displaying the exact location should it experience a failure. Utilising this real-time software, replacing the relevant part becomes an efficient procedure.
Factory calibrated
Calibrated in our factory under perfect conditions, Philips direct view LED installations are more efficient, with no need for on-site calibration. For fast and effective maintenance, all configuration files are available online.
Dynamic Panel Connect
Mix and match panel sizes to form a single LED wall of any shape and size. Dynamic flexible alignment ensures a perfect fit and a smooth, seamless surface. For added efficiency, each panel features openings on either side for versatile wired connections between panels and any external input connection.
Built-in cable and data wiring
Your Philips professional LED Display features built-in cable wiring to keep power and data cables tidy. Display cabinets are daisy-chained for both power and data, allowing you to minimise clutter and speed up installation.
High performance displays
Achieve perfection through precision. Quality and performance go hand-in-hand with Philips professional displays designed, manufactured, calibrated and thoroughly tested in-house.
IP30 rated conformal coating
Dust, dirt, fungus and moisture resistant conformal coating protects this product and enables easier maintenance. IP30 rated and certified against ingress for reduced chance of short circuit from dust and corrosion.
Optional easy-mount brackets
Patented easy-mount brackets make installation even faster. These optional items are available for flat LED mounting, convex curved (177.5/175/172.5 degree), and L-shape 90 degree corners.
Unique in every way
Go with the flow with a modular Philips LED display that can adapt to any shape, size or resolution. Build vast installations or assemble intriguing patterns. Flex seamlessly around doorways and openings, and move elegantly through corners and curves.
Certified fire retardancy
Fire retardant design slows down the spread of flames in the event of fire. Tested and certified with British standard (BS476), B1 DIN4102, and UL94.
Limitless videowall
L-Line creates an LED videowall of any shape or size for a truly unique experience.
Technical Specifications
Picture/Display
Color temperature default | 6500±500 K |
---|---|
Color temperature adjust range | 4000~9500 K (by software) |
Viewing angle (horizontal) | 160 |
Viewing angle (vertical) | 160 |
Calibration(brightness/color) | Supported |
Refresh rate(Hz) | 2100~3900 (14 bits: 3900Hz) |
Frame frequency (Hz) | 50 & 60 |
Aspect ratio | 4:1 |
Picture enhancement | Wide color gamut display |
Placement | Landscape |
Usage | Indoor |
Brightness uniformity | >=97% |
Brightness before calibration | 1200 nits |
Brightness after calibration | 900 nits |
Contrast ratio (typical) | 3500:1 |
Convenience
Signal control loop through | RJ45 |
---|---|
Ease of installation | Guide pins |
Light weight | |
Power loop through | For 230V environments: 8 cabinets or less, for 110V environments: 4 cabinets or less, 10A max |
Operating conditions
Temperature range (operation) | -20~45 |
---|---|
Temperature range (storage) | -20~50 |
Humidity range (operation)[RH] | 10~80% |
Humidity range (storage) [RH] | 10~85% |
Power
Input voltage | AC100~240V (50 & 60Hz) |
---|---|
Max. power cons. BC (W) | <150 |
Typical power cons. (W) | <41.67 |
Black screen power cons. (W) | <11 |
Max. power cons. AC (W) | <125 |
Miscellaneous
Warranty | 2 years |
---|---|
Regulatory approvals | EN55032 |
EN55035 | |
EN61000-3-2 | |
EN61000-3-3 | |
IEC/UL60950 | |
IEC/UL62368 | |
IEC62471 | |
RoHS | |
FCC SDOC, Part 15, Class A | |
Fire retardancy certification | BS 476 Part7:1997 |
UL94 | |
DIN4102-1 | |
Conformal coating | hub board, backside LED module |
Cabinet
Cabinet size (mm) | 1000x250x40 |
---|---|
Side angle (degree) | 45 |
Cabinet diagonal (inch) | 40.6" |
Cabinet resolution (W x H) | 416x104 |
Weight (KG) | 5.91 (±300g) |
Cabinet pixels ( Dot ) | 43.264 |
Cabinet area (m2) | 0.25 |
Power connector | 3 core socket (C14 in, C13 out) |
Data connector | RJ45 |
Cabinet construction | Die-Casting Aluminum |
Receiving card quantity | 1 pcs |
Receiving card spec. | A5S plus |
Receving card brand | NovaStar |
Module
LED type | SMD 1515 Copper wire |
---|---|
Pixel constitution | 1R1G1B |
LED lifetime(Hrs) | 100,000 at half brightness |
Pixel pitch (mm) | 2.4 |
Module resolution (WxH pixels) | 104x104 |
Module size (WxH in mm) | 249.9*249.9 |
Accessories
Power cable | 2 pcs |
---|---|
LAN cable (RJ45, CAT-5) | 2 pcs |
QSG | 1 pcs |
Packaging Data
Dimension of packaging (mm) | 1354x392x221 |
---|---|
Gross weight (KG) | 9.01 |
