E-Line

75BDL4152E/00

Energy Label: g. epeat silver.

This interactive display maximises engagement and inspires collaboration with up to 40 touchpoints. Powered by Android 13 and with toughened anti-glare, anti-reflection and anti-fingerprint glass, it's ideal for heavy daily use in busy environments.

Get a quote

Technical Specifications

Weight

Product without stand (kg)45.5 kg
Product with packaging (lb)125.22 lb
Product without stand (lb)100.31 lb
Product with packaging (kg)56.8 kg

Miscellaneous

On-Screen Display LanguagesArabic
Dutch
Danish
English
French
Finnish
German
Italian
Japanese
Norwegian
Polish
Portuguese
Russian
Spanish
Swedish
Simplified Chinese
Turkish
Traditional Chinese
Regulatory approvalsCE
FCC, Class A
RoHS
CB
EAC
EMF
ETL
Warranty5-year warranty

Operating conditions

Temperature range (storage)-20 ~ 60 °C
Temperature range (operation)0 ~ 40 °C
Humidity range (operation)[RH]20–80% (without condensation)
Altitude0 ~ 3000 m
Humidity range (storage) [RH]5–95% (without condensation)
MTBF50,000 hour(s)

Picture/Display

Pixel pitch0.4296 x 0.4296 mm
Panel resolution3840 x 2160
Diagonal screen size (metric)189.3 cm
Brightness400 cd/m²
OS UI resolution3840 x 2160 @ 60 Hz
Picture enhancement3/2 - 2/2 motion pull down
3D Combfilter
Motion compens. deinterlacing
Progressive scan
3D MA deinterlacing
Dynamic contrast enhancement
Optimum resolution3840 x 2160 @ 60 Hz
Display colours1.07 billion
Viewing angle (horizontal)178 degree
Dynamic contrast ratio500,000:1
Aspect ratio16:9
Response time (typical)8 ms
Operating systemAndroid 13
Diagonal screen size (inch)74.5 inch
Contrast ratio (typical)1200:1
Viewing angle (vertical)178 degree
Panel technologyADS

Supported Display Resolution

Video formats480p, 60 Hz
720p, 50, 60 Hz
1080i, 50, 60 Hz
1080p, 50, 60 Hz
2160p, 50, 60 Hz
480i, 60 Hz
Computer formats800 x 600, 56, 60, 72, 75 Hz
848 x 480, 60 Hz
1024 x 768, 60, 70, 75, 85 Hz
1152 x 864, 75 Hz
1280 x 960, 60, 85 Hz
1280 x 1024, 60, 67, 75 Hz
1360 x 768, 60 Hz
1366 x 768, 60 Hz
1600 x 1200, 60 Hz
1920 x 1080, 60 Hz
1920 x 1200, 60 Hz
3840 x 2160, 24, 25, 30, 60 Hz

Interactivity

Protection glassAnti-Glare
Blue light filter
Tempered safety glass 7 MOHS
Multi-touch technology0-gap Infrared touch
Plug and playHID compliant
Touchpoints40 simultaneous touchpoints

Connectivity

Audio output3.5 mm Mini Jack (x 1)
Video outputHDMI 2.0 (x 1)
Video inputHDMI 2.0 (x 3)
USB 3.0 (x 2)
USB 2.0 (x 1)
USB-C (up to 65 W)
USB-C
Bluetooth5.2 BLE
Other connectionsOPS
USB-B (x 2)
Micro USB (x 1) (OTG)
External controlIR (in/out) 3.5 mm jack
RS232C (in/out) 2.5 mm jack
Gb LAN x 2
Audio input3.5 mm mini jack (x 1)

Convenience

Remote control signalLockable
PlacementLandscape (18/7)
Screen-saving functionsPixel Shift, Low Brightness
Network controllableRS232
RJ45
Other convenienceCarrying handles
NFC
Bluetooth
Signal loop throughRS232
IR Loop through
Keyboard controlLockable

Accessories

Optional accessoriesPen tray with 3 x colour stylus and eraser
Included AccessoriesCleaning cloth (x 1)
AC Power Cord
Philips logo (x 1)
Quick start guide (x 1)
Remote control and AAA batteries
USB A to B cable (3 m) (x 1)
AC switch cover and Screw x 1
HDMI cable (1.8 m) (x 1)
Touch Pen (x 2)

Internal Player

Storage32 GB eMMc
Memory8 GB
GPUMulti-Core Mali-G52
CPU4 x A73 + 4 x A53
Wi-Fi2T/2R 2.4/5/6 GHz

Dimensions

Set Height1018.3 mm
Wall Mount600 x 400 mm, M8
Set Width1715.2 mm
Set Depth116.15 mm
Set Width (inch)67.53 inch
Set Height (inch)40.09 inch
Bezel width16.7 mm(T/R/L), 41.5 mm(B)
Set Depth (inch)4.57 inch

Sound

Built-in speakers2 x 20 W

Power

Energy Label ClassG. EPEAT Silver.
Power Saving FeaturesSmart Power
Consumption (Typical)155 W
Standby power consumption<0.5 W
Mains power100 ~ 240 VAC, 50/60 Hz

Multimedia Applications

USB Playback VideoH.263
H.264
H.265
MPEG1/2
MPEG4
VP8
VP9
USB Playback PictureBMP
JPEG
PNG
WEBP
USB Playback AudioAAC
HEAAC
MPEG
