E-Line

86BDL4152E/00

This interactive display maximises engagement and inspires collaboration with up to 40 touchpoints. Powered by Android 13 and with toughened anti-glare, anti-reflection and anti-fingerprint glass, it's ideal for heavy daily use in busy environments.

Get a quote

Technical Specifications

Operating conditions

Temperature range (storage)	-20 ~ 60 °C
Humidity range (storage) [RH]	5–95% (without condensation)
Humidity range (operation)[RH]	20–80% (without condensation)
Altitude	0 ~ 3000 m
Temperature range (operation)	0 ~ 40 °C
MTBF	50,000 hour(s)

Miscellaneous

On-Screen Display Languages	Arabic
	Dutch
	Danish
	English
	French
	Finnish
	German
	Italian
	Japanese
	Norwegian
	Polish
	Portuguese
	Russian
	Spanish
	Swedish
	Simplified Chinese
	Turkish
	Traditional Chinese
Regulatory approvals	CE
	FCC, Class A
	RoHS
	CB
	EAC
	EMF
	ETL
Warranty	5-year warranty

Weight

Product without stand (kg)	57 kg kg
Product with packaging (lb)	155.87 lb
Product without stand (lb)	125.66 lb
Product with packaging (kg)	70.7 kg

Picture/Display

Diagonal screen size (metric)	217.4 cm
Panel resolution	3840 x 2160
Pixel pitch	0.4935 x 0.4935 mm
Brightness	400 cd/m²
Optimum resolution	3840 x 2160 @ 60 Hz
Picture enhancement	3/2 - 2/2 motion pull down
	3D Combfilter
	Motion compens. deinterlacing
	Progressive scan
	3D MA deinterlacing
	Dynamic contrast enhancement
OS UI resolution	3840 x 2160 @ 60 Hz
Display colours	1.07 billion
Viewing angle (horizontal)	178 degree
Dynamic contrast ratio	500,000:1
Aspect ratio	16:9
Panel technology	ADS
Contrast ratio (typical)	1200:1
Diagonal screen size (inch)	85.6 inch
Response time (typical)	8 ms
Operating system	Android 13
Viewing angle (vertical)	178 degree

Supported Display Resolution

Video formats	480p, 60 Hz
	1080i, 50, 60 Hz
	1080p, 50, 60 Hz
	2160p, 50, 60 Hz
	480i, 60 Hz
	720p, 50, 60 Hz
Computer formats	800 x 600, 56, 60, 72, 75 Hz
	848 x 480, 60 Hz
	1024 x 768, 60, 70, 75, 85 Hz
	1152 x 864, 75 Hz
	1280 x 960, 60, 85 Hz
	1280 x 1024, 60, 67, 75 Hz
	1360 x 768, 60 Hz
	1366 x 768, 60 Hz
	1600 x 1200, 60 Hz
	1920 x 1080, 60 Hz
	1920 x 1200, 60 Hz
	3840 x 2160, 24, 25, 30, 60 Hz

Interactivity

Protection glass	Anti-Glare
	Blue light filter
	Tempered safety glass 7 MOHS
Multi-touch technology	0-gap Infrared touch
Plug and play	HID compliant
Touchpoints	40 simultaneous touchpoints

Connectivity

Video output	HDMI 2.0 (x 1)
Audio output	3.5 mm Mini Jack (x 1)
Video input	HDMI 2.0 (x 3)
	USB 3.0 (x 2)
	USB 2.0 (x 1)
	USB-C (up to 65 W)
	USB-C
Other connections	OPS
	USB-B (x 2)
	Micro USB (x 1) (OTG)
External control	IR (in/out) 3.5 mm jack
	RS232C (in/out) 2.5 mm jack
	Gb LAN x 2
Bluetooth	5.2 BLE
Audio input	3.5 mm mini jack (x 1)

Convenience

Remote control signal	Lockable
Screen-saving functions	Pixel Shift, Low Brightness
Placement	Landscape (18/7)
Network controllable	RS232
	RJ45
Signal loop through	RS232
	IR Loop through
Other convenience	Carrying handles
	NFC
	Bluetooth
Keyboard control	Lockable

Accessories

Optional accessories	Pen tray with 3 x colour stylus and eraser
Included Accessories	Cleaning cloth (x 1)
	Remote control and AAA batteries
	USB A to B cable (3 m) (x 1)
	AC Power Cord
	Philips logo (x 1)
	Quick start guide (x 1)
	AC switch cover and Screw x 1
	HDMI cable (1.8 m) (x 1)
	Touch Pen (x 2)

Internal Player

Storage	32 GB eMMc
Memory	8 GB
GPU	Multi-Core Mali-G52
CPU	4 x A73 + 4 x A53
Wi-Fi	2T/2R 2.4/5/6 GHz

Dimensions

Wall Mount	800 x 400 mm, M8
Set Height	1158.74 mm
Set Width	1965.1 mm
Set Depth	116.227 mm
Set Width (inch)	77.37 inch
Bezel width	16.7 mm(T/R/L), 39.42 mm(B)
Set Height (inch)	45.62 inch
Set Depth (inch)	4.58 inch

Sound

Built-in speakers	2 x 20 W

Power

Energy Label Class	G. EPEAT Silver.
Power Saving Features	Smart Power
Consumption (Typical)	190W W
Mains power	100 - 240 V~, 50 - 60 Hz, 7.5 A
Standby power consumption	<0.5 W
