Technical Specifications
Cabinet
| Cabinet construction | Profile Aluminium |
|---|---|
| Data connector | Seetronic |
| Cabinet resolution (W x H) | 168 x 168 pixels |
| Power connector | Seetronic |
| Control System | Novastar |
| Cabinet pixels (Dot) | 28224 |
| Cabinet area (m2) | 0.25 |
| Cabinet size (inches) | 28" |
| Weight (kg) | 9.0±0.5 kg |
| Cabinet Size (W x H x D in mm) | 500 x 500 x 80.4 |
Power
| Cabinet Typical Power consumption (W) (AC) | 48 |
|---|---|
| BTU/M2 (AC) | 1636.80 |
| Input voltage | AC100~240 V (50 and 60 Hz) |
| Power consumption/M2 (W) (BC) | 580 |
| Power consumption/M2 (W) (AC) | 480 |
| BTU/M2 (BC) | 1977.80 |
Miscellaneous
| Certification | TUV |
|---|---|
| Regulatory approvals | CB |
| CE | |
| ETL | |
| FCC | |
| Warranty | 24 months |
Operating conditions
| Working environment (indoor/outdoor) | outdoor |
|---|---|
| Temperature range (storage) | -40~60 °C |
| Humidity range (operation)[RH] | 10%–90% |
| Humidity range (storage) [RH] | 10%–70% |
| Temperature range (operation) | -30~50 °C |
| IP Rating (front/rear) | IP66/65 |
Picture/Display
| Calibration (brightness/colour) | Colour and Brightness |
|---|---|
| Brightness before calibration | 4000 |
| Colour temperature adjust range | 3000~10000 |
| Contrast ratio | 5000:1 |
| Frame frequency (Hz) | 50 - 60 |
| Refresh rate (Hz) | 3840 Hz (with CE report and cert.) |
| Viewing angle (°) H/V | 160/90 |
| Brightness after calibration | 3500 |
| Colour temperature default | 8000 |
| Bit-depth (bit) | 14 |
Module
| LED size | SMD1415 |
|---|---|
| Module size (W x H in mm) | 250 x 250 |
| Pixel constitution | 1R1G1B |
| Weight (kg) | 1±0.1 kg |
| Pixel pitch (mm) | 2.9 |
| LED Lifetime (hrs, half brightness) | 100 000 |
| Module resolution (WxH pixels) | 84 x 84 |
| LED type | SMD |
