Technical Specifications
Picture/Display
Diagonal screen size (metric) | 80 |
---|---|
Diagonal screen size (inch) | 32 |
Panel resolution | 1920 x 1080p |
Optimum resolution | 1920 x 1080 @ 60 Hz |
Brightness | 350 |
Contrast ratio (typical) | 4000:1 |
Surface treatment | Anti-Glare coating |
Aspect ratio | 16:9 |
Response time (typical) | 6.5 |
Pixel pitch | 0.36375 (H) X 0.36375 (V) mm |
Display colours | 16.7 M |
Viewing angle (horizontal) | 178 |
Viewing angle (vertical) | 178 |
Panel technology | VA |
Operating system | Android 8.0 |
Picture enhancement | 3/2 - 2/2 motion pull down |
3D Combfilter | |
3D MA deinterlacing | |
Dynamic contrast enhancement | |
Motion compens. deinterlacing | |
Progressive scan |
Interactivity
Multi-touch technology | Projected capacitive |
---|---|
Touch points | 10 simultaneous touch points |
Plug and play | HID compliant |
Protection glass | 2 mm tempered safety glass |
Connectivity
Video input | DVI-I (x 1) |
---|---|
HDMI 2.0 (x 2) | |
USB 2.0 Type A (x 2) | |
USB 2.0 Type B (x 1) | |
VGA (via DVI-I) x 1 | |
Audio input | 3.5 mm jack |
Audio output | 3.5 mm jack |
External control | RJ45 |
IR (in/out) 3.5 mm jack | |
RS232C (in/out) 2.5 mm jack | |
Other connections | micro SD |
Supported Display Resolution
Computer formats | 640 x 480, 60, 67, 72, 75 Hz |
---|---|
800 x 600, 56, 60, 72, 75 Hz | |
1024 x 768, 60 Hz | |
1280 x 768, 60 Hz | |
1280 x 800, 60 Hz | |
1280 x 1024, 60 Hz | |
1360 x 768, 60 Hz | |
1366 x 768, 60 Hz | |
1440 x 900, 60 Hz | |
1600 x 1200, 60 Hz | |
1920 x 1080, 60 Hz | |
1920 x 1200, 60 Hz | |
720 x 400, 70 Hz | |
800 x 600, 60, 72, 75 Hz | |
3840 x 2160, 60 Hz, 50 Hz | |
Video formats | 480i, 60 Hz |
480p, 60 Hz | |
576p, 50 Hz | |
576i, 50 Hz | |
720p, 50, 60 Hz | |
1080i, 50, 60 Hz | |
1080p, 50, 60 Hz | |
1080i, 25, 30 Hz | |
480i, 30, 60 Hz | |
576i, 25, 50 Hz | |
3840 x 2160, 24, 25 Hz | |
3840 x 2160, 30Hz |
Convenience
Placement | Landscape (18/7) |
---|---|
Portrait (18/7) | |
Signal loop through | IR Loop through |
RS232 | |
Network controllable | RS232 |
RJ45 | |
Screen-saving functions | Pixel Shift, Low Brightness |
Keyboard control | Hidden |
Lockable | |
Remote control signal | Lockable |
Energy-saving functions | Smart Power |
Dimensions
Set Width | 749.1 |
---|---|
Set Height | 443.6 |
Set Depth | 70.4 (D@Wall mount)/74.4 (D@AC) |
Set Width (inch) | 29.49 |
Set Height (inch) | 17.46 |
Set Depth (inch) | 2.77 D@Wall mount)/2.93 (D@AC) |
Product weight | 8.0 |
Product weight (lb) | 17.64 |
Wall Mount | 100 mm x 100 mm, 200 mm x 200 mm, M4 |
Bezel width | 2.0 mm (T/R/L/B) |
Sound
Built-in speakers | 2 x 10 W |
---|
Operating conditions
Temperature range (operation) | 0 ~ 40 |
---|---|
MTBF | 50,000 |
Altitude | 0 ~ 3000 m |
Temperature range (storage) | -20~60 |
Humidity range (operation)[RH] | 20–80% (without condensation) |
Humidity range (storage) [RH] | 5–95% (without condensation) |
Power
Mains power | 100 ~ 240 VAC, 50/60 Hz |
---|---|
Standby power consumption | <0.5 W |
Consumption (Typical) | 50 |
Power Saving Features | Smart Power |
Consumption (Max) | 80 W |
Energy Label Class | G |
Accessories
Stand | BM05922 (Optional) |
---|---|
Included Accessories | Cleaning cloth (x 1) |
IR sensor cable (1.8 m) (x 1) | |
Philips logo (x 1) | |
Power supply cable (3 m) | |
Quick start guide (x 1) | |
Remote control and AAA batteries | |
RS232 cable (3 m) (x 1) | |
RS232 daisy chain cable (x 1) | |
USB Cover and screw x 1 |
Miscellaneous
On-Screen Display Languages | Arabic |
---|---|
English | |
French | |
German | |
Italian | |
Japanese | |
Polish | |
Spanish | |
Turkish | |
Russian | |
Simplified Chinese | |
Traditional Chinese | |
Danish | |
Dutch | |
Finnish | |
Norwegian | |
Portuguese | |
Swedish | |
Regulatory approvals | CB |
CE | |
FCC, Class A | |
RoHS | |
BSMI | |
CU | |
ETL | |
IMDA | |
PSB | |
Warranty | 3 year warranty |
Multimedia Applications
USB Playback Picture | BMP |
---|---|
GIF | |
JPEG | |
JPG | |
USB Playback Audio | AAC |
AIF | |
AIFF | |
ASF | |
LPCM | |
M3U | |
M4A | |
MP3 | |
MP4 | |
WAV | |
WMA | |
USB Playback Video | M2TS |
M4V | |
MK3D | |
MKV | |
MP4 | |
MPEG | |
MPG | |
MTS | |
TS | |
TTS | |
VOB | |
WMV |
Internal Player
CPU | 2 x A53 + 2 x A73 |
---|---|
Memory | 2 GB DDR3 |
8 GB | |
GPU | ARM Mali G51 |
Wi-Fi | 2.4 G |
5 G |
