Technical Specifications
Picture/Display
Diagonal screen size (metric) | 138.7 |
---|---|
Diagonal screen size (inch) | 54.6 |
Panel resolution | 3840 x 2160 |
Optimum resolution | 3840 x 2160 @ 60 Hz |
Brightness | 500 |
Dynamic contrast ratio | 500,000:1 |
Response time (typical) | 8 |
Aspect ratio | 16:9 |
Viewing angle (horizontal) | 178 |
Viewing angle (vertical) | 178 |
Pixel pitch | 0.315 × 0.315 mm |
Display colours | 1.07 Billion |
Panel technology | VA |
Contrast ratio (typical) | 5000:1 |
Haze | 25% |
Supported Display Resolution
Computer formats | 640 x 480, 60 Hz |
---|---|
800 x 600, 60 Hz | |
1024 x 768, 60 Hz | |
1280 x 720, 60 Hz | |
1280 x 1024, 60 Hz | |
1440 x 900, 60 Hz | |
1600 x 900, 60 Hz | |
1680 x 1050, 60 Hz | |
1920 x 1080, 60 Hz | |
3840 x 2160, 30, 60 Hz | |
Video formats | 480i, 60 Hz |
480p, 60 Hz | |
576p, 50 Hz | |
576i, 50 Hz | |
720p, 50,60 Hz | |
1080i, 50, 60 Hz | |
1080p, 50, 60 Hz | |
2160p, 24, 30, 60 Hz |
Connectivity
Video input | Display Port1.2 (x 1) |
---|---|
DVI-I (x 1) | |
HDMI 2.0 (x 2) | |
USB 2.0 (x 2) | |
Audio input | 3.5 mm jack |
Video output | DisplayPort 1.2 (x 1) |
HDMI 2.0 (x 1) | |
Audio output | 3.5 mm jack |
External control | IR (in/out) 3.5 mm jack |
RJ45 | |
RS232C (in/out) 2.5 mm jack | |
Other connections | OPS |
Convenience
Placement | Landscape (24/7) |
---|---|
Portrait (24/7) | |
Screen-saving functions | Pixel Shift, Low Bright |
Signal loop through | DisplayPort |
RS232 | |
HDMI | |
IR Loop through | |
Energy-saving functions | Smart Power |
Network controllable | RS232 |
RJ45 | |
Keyboard control | Hidden |
Lockable |
Operating conditions
Temperature range (operation) | 0 ~ 40 |
---|---|
Temperature range (storage) | -20 ~ 60 |
Altitude | 0 ~ 3000 m |
MTBF | 50,000 |
Humidity range (operation)[RH] | 20–80% RH (No condensation) |
Humidity range (storage) [RH] | 5–95% RH (No condensation) |
Power
Consumption (Typical) | 135 |
---|---|
Consumption (Max) | 278 W |
Standby power consumption | 0.5 W |
Mains power | 100 ~ 240 VAC, 50 ~ 60 Hz |
Energy Label Class | G |
Sound
Built-in speakers | 2 x 10 W RMS |
---|
Accessories
Stand | BM05922(Optional) |
---|---|
Included Accessories | AC Switch Cover |
Philips logo (x 1) | |
RS232 daisy-chain cable | |
AC power cord | |
IR sensor cable (1.8 m) (x 1) | |
Quick start guide (x 1) | |
Remote control and AAA batteries | |
RS232 cable | |
USB Cover and screw x 1 | |
Wire Clamper (x 3) |
Miscellaneous
On-Screen Display Languages | Arabic |
---|---|
Dutch | |
Danish | |
English | |
French | |
Finnish | |
German | |
Italian | |
Japanese | |
Norwegian | |
Polish | |
Portuguese | |
Russian | |
Spanish | |
Swedish | |
Simplified Chinese | |
Turkish | |
Traditional Chinese | |
Regulatory approvals | CE |
FCC, Class A | |
CCC | |
RoHS | |
CB | |
BSMI | |
EMF | |
VCCI | |
PSB | |
ETL | |
CECP | |
EAC | |
Warranty | 3 year warranty |
Multimedia Applications
USB Playback Video | H.263 |
---|---|
H.264 | |
H.265 | |
MPEG | |
USB Playback Picture | BMP |
JPEG | |
PNG | |
USB Playback Audio | AAC |
MPEG | |
HEAAC |
Dimensions
Set Width | 1241.8 |
---|---|
Set Height | 712.6 |
Set Depth | 63.6 |
Set Width (inch) | 48.89 |
Set Height (inch) | 28.06 |
Set Depth (inch) | 2.50 |
Bezel width | 13.9 mm (Even bezel) |
Wall Mount | 400 (H) x 400(V) mm, M6 |
Product weight | 16.6 |
Product weight (lb) | 36.60 |
