Q-Line

65BDL4050Q/00

Inform and enthral with Philips Signage 4050 Q-Line. UHD resolution is matched with enhanced brightness and high haze, and the efficiency of the tried and tested Android 10 SoC. Wave-ready for remote management, putting you in full control.

Get a quote

Technical Specifications

Connectivity

Audio output	3.5mm jack
Other connections	micro SD
	OPS
Video input	USB 2.0 (x2)
	DVI-I (x 1)
	HDMI 2.0 (x2)
	USB 3.0 (x1)
Audio input	3.5 mm jack
External control	RS232C (in/out) 2.5 mm jack
	IR (in/out) 3.5 mm jack
	RJ45

Convenience

Remote control signal	Lockable
Energy saving functions	Smart Power
Tiled Matrix	Up to 3 x 3
Ease of installation	Smart Insert
Keyboard control	Hidden
	Lockable
Network controllable	RS232
	RJ45
Placement	Landscape (24/7)
	Portrait (24/7)
Signal loop through	RS232
	IR Loopthrough

Accessories

Included Accessories	RS232 daisy-chain cable
	Philips logo (x1)
	AC Power Cord
	AC Switch Cover
	Quick start guide
	Remote control & AAA batteries
	RS232 cable
	USB Cover (x1)

Dimensions

Product weight	28.5 kg
Set Width	1462.3 mm
Set Height	837.3 mm
Set Depth (inch)	2.71(@ wall mount) / 3.54(@ handle) inch
Wall Mount	400 mm x 400 mm, M8
Product weight (lb)	62.83 lb
Set Width (inch)	57.57 inch
Set Depth	68.9mm(D@wall mount) / 89.9mm(D@handle) mm
Set Height (inch)	32.96 inch
Bezel width	14.9 mm (Even bezel)

Internal Player

GPU	G52 MC1
Memory	16GB
	3GB DDR
CPU	Quad Core Cortex A55

Sound

Built-in speakers	2 x 10W RMS

Power

Standby power consumption	<0.5W
Mains power	100 - 240V~, 50/60Hz
Power Saving Features	Smart Power
Energy Label Class	G

Multimedia Applications

USB Playback Picture	JPEG
	PNG
	BMP
	WEBP
USB Playback Video	MPEG 1/2 (1080p 60Hz)
	MPEG 4 (1080p 60Hz)
	H.263 (1080p 60Hz)
	H.264 (4K2K 60Hz)
	H.265 (4K2K 60Hz)
	VP8 (1080p 60Hz)
	VP9 (4K2K 60Hz)
USB Playback Audio	AAC
	HEAAC
	MPEG 1/2/2.5 Layer 3
	MPEG 1/2 Layer 1
	MPEG 1/2 Layer 2

Operating conditions

Humidity range (operation)[RH]	20 ~ 80% RH (No condensation)
MTBF	50,000 hour(s)
Altitude	0 ~ 3000 m
Humidity range (storage) [RH]	5 ~ 95% RH (No condensation)
Temperature range (storage)	-20 ~ 60 °C
Temperature range (operation)	0 ~ 40 °C

Miscellaneous

On-Screen Display Languages	Simplified Chinese
	Traditional Chinese
	English
	French
	German
	Italian
	Polish
	Russian
	Spanish
	Turkish
	Japanese
	Arabic
Regulatory approvals	CE
	CB
	FCC, Class A
	VCCI
	RoHS
	UL
Warranty	3 year warranty

Picture/Display

Viewing angle (horizontal)	178 degree
Viewing angle (vertical)	178 degree
Response time (typical)	8 ms
Picture enhancement	3/2 - 2/2 motion pull down
	Progressive scan
	Dynamic contrast enhancement
Contrast ratio (typical)	1200:1
Diagonal screen size (inch)	64.5 inch
Aspect ratio	16:9
Dynamic contrast ratio	500,000:1
Operating system	Android 10
Haze	25%
Optimum resolution	3840 x 2160 @ 60 Hz
Panel resolution	3840 x 2160
Diagonal screen size (metric)	163.9 cm
Display colors	1.07 Billion
Brightness	500 cd/m²
Pixel pitch	0.372 x 0.372 mm
Panel technology	ADS

Supported Display Resolution

Computer formats	720 x 400, 70Hz
	640 x 480, 60,67,75Hz
	800 x 600, 60Hz
	832 x 624, 75Hz
	1024 x 768, 60Hz
	1152 x 870, 75Hz
	1280 x 720, 60Hz
	1920 x 1080, 60Hz
	1680 x 1050, 60Hz
	3840 x 2160, 30, 60Hz
Video formats	480i, 60Hz
	480p, 60Hz
	576p, 50Hz
	576i, 50Hz
	720p, 50, 60Hz
	1080i, 50, 60Hz
	1080p, 50, 60Hz
	3840 x 2160, 30, 60Hz
