Q-Line

98BDL3650Q/00

Inform and enthral with a Philips Q-Line 4K Ultra HD digital display. This reliable, easy-to-install, Android powered signage solution is Wave-ready for remote management, putting you in full control, any time, anywhere.

Get a quote

Technical Specifications

Connectivity

Other connections	micro SD
	OPS
Audio output	3.5mm jack
Video input	USB 2.0 (x2)
	DVI-I (x 1)
	HDMI 2.0 (x2)
	USB 3.0 (x1)
Audio input	3.5 mm jack
External control	RS232C (in/out) 2.5 mm jack
	IR (in/out) 3.5 mm jack
	RJ45

Convenience

Tiled Matrix	Up to 3 x 3
Energy saving functions	Smart Power
Remote control signal	Lockable
Ease of installation	Smart Insert
Signal loop through	RS232
	IR Loopthrough
Placement	Landscape (18/7)
	Portrait (18/7)
Keyboard control	Hidden
	Lockable
Network controllable	RS232
	RJ45

Accessories

Included Accessories	IR sensor cable (1.8 m) (x1)
	RS232 daisy-chain cable
	Philips logo (x1)
	AC Power Cord
	AC Switch Cover
	Quick start guide
	Remote control & AAA batteries
	RS232 cable
	USB cover and screws
	Wire Clamper (x3)

Dimensions

Set Width	2193.4 mm
Set Height	1255.3 mm
Product weight	65.2 kg
Set Depth (inch)	3.54 inch
Wall Mount	1000 mm x 400 mm, M8
Product weight (lb)	143.74 lb
Bezel width	15.9mm: L/R/T , 20.1mm: B
Set Height (inch)	49.42 inch
Set Width (inch)	86.35 inch
Set Depth	90 mm

Internal Player

Memory	16GB
	3GB DDR
GPU	G52 MC1
CPU	Quad Core Cortex A55

Sound

Built-in speakers	2 x 10W RMS

Power

Standby power consumption	<0.5W
Consumption (Typical)	204 W
Power Saving Features	Smart Power
Mains power	100 - 240V~, 50/60Hz
Energy Label Class	G

Multimedia Applications

USB Playback Video	MPEG
	H.264
	H.263
	H.265
	AVI
	MP4
	VP8
USB Playback Picture	BMP
	JPEG
	PNG
USB Playback Audio	AAC
	HEAAC
	MPEG

Operating conditions

MTBF	50,000 hour(s)
Humidity range (operation)[RH]	20 ~ 80% RH (No condensation)
Altitude	0 ~ 3000 m
Humidity range (storage) [RH]	5 ~ 95% RH (No condensation)
Temperature range (storage)	-20 ~ 60 °C
Temperature range (operation)	0 ~ 40 °C

Miscellaneous

On-Screen Display Languages	Simplified Chinese
	Traditional Chinese
	English
	French
	German
	Italian
	Polish
	Russian
	Spanish
	Turkish
	Japanese
	Arabic
Warranty	3 year warranty
Regulatory approvals	CE
	CB
	FCC, Class A
	VCCI
	RoHS
	UL

Picture/Display

Picture enhancement	3/2 - 2/2 motion pull down
	Progressive scan
	Dynamic contrast enhancement
Contrast ratio (typical)	1200:1
Response time (typical)	8 ms
Viewing angle (horizontal)	178 degree
Viewing angle (vertical)	178 degree
Optimum resolution	3840 x 2160 @ 60 Hz
Haze	25%
Operating system	Android 10
Dynamic contrast ratio	500,000:1
Diagonal screen size (inch)	97.5 inch
Aspect ratio	16:9
Panel resolution	3840 x 2160
Display colors	1.07 Billion
Diagonal screen size (metric)	247.7 cm
Panel technology	IPS
Pixel pitch	0.56 x 0.56 mm
Brightness	400 cd/m²

Supported Display Resolution

Computer formats	1920 x 1080, 60Hz
	1680 x 1050, 60Hz
	1600 x 1200, 60Hz
	1440 x 900, 60Hz
	1280 x 1024, 60Hz
	1280 x 800, 60Hz
	1280 x 720, 60Hz
	1024 x 768, 60, 70, 75Hz
	3840 x 2160, 60Hz
Video formats	1080p, 50, 60Hz
	1080i, 50, 60Hz
	720p, 50,60 Hz
	2160p, 50, 60Hz
