Q-Line

86BDL3550Q/00

Inform and enthrall with a Philips Q-Line Professional Ultral HD Display. This reliable solution can be up and running as quickly as you need.

Get a quote

CMND & Control

Run your display network over a local (LAN or RF) connection. CMND & Control allows you to perform vital functions like updating software and settings, as well as monitoring display status. Whether you’re in charge of one TV or more, CMND & Control makes managing your fleet easy.

FailOver

From waiting room to meeting room, never show a blank screen. FailOver lets your Philips professional display switch automatically between primary and secondary inputs, ensuring that content keeps playing even if the primary source goes down. Simply set a list of alternative inputs to be sure your business is always on.

OPS Slot

Integrate a full-power PC or Android-powered CRD50 module directly into your Philips professional display. The OPS slot contains all the connections you need to run your slot-in solution, including a power supply.

CMND & Create

Take control of your content with CMND and Create. A drag-and-drop interface makes it simple to publish your own content, whether it's a daily specials board or branded corporate information. Preloaded templates and integrated widgets ensure that your stills, text and video will be up and running in no time.

Integrated Media Player

Easily schedule content to play from USB. Your Philips professional display will wake from standby to play the content you want, and then return to standby once playback has finished.

Powered by Android

With Android on your professional display you'll enjoy a faster, richer and guest-friendly interface. It's your launch control to a wealth of dedicated hospitality services, applications and so much more. There's an easy-to-navigate menu with direct links to your favourite apps.

Discover Android

Integrated HTML5 browser

Connect and control your content over the internet with the integrated HTML5 browser. Using the Chromium-based browser, design your content online and connect a single display or your complete network. Show content in both landscape and portrait mode, with full-HD resolution. Streaming content can also be shown in a PIP (picture-in-picture) window. Simply connect the display to the internet using WiFi or with an RJ45 cable, and enjoy your own created playlist

CMND & Control

Run your display network over a local (LAN or RF) connection. CMND & Control allows you to perform vital functions like updating software and settings, as well as monitoring display status. Whether you’re in charge of one TV or more, CMND & Control makes managing your fleet easy.

FailOver

From waiting room to meeting room, never show a blank screen. FailOver lets your Philips professional display switch automatically between primary and secondary inputs, ensuring that content keeps playing even if the primary source goes down. Simply set a list of alternative inputs to be sure your business is always on.

OPS Slot

Integrate a full-power PC or Android-powered CRD50 module directly into your Philips professional display. The OPS slot contains all the connections you need to run your slot-in solution, including a power supply.

CMND & Create

Take control of your content with CMND and Create. A drag-and-drop interface makes it simple to publish your own content, whether it's a daily specials board or branded corporate information. Preloaded templates and integrated widgets ensure that your stills, text and video will be up and running in no time.

Integrated Media Player

Easily schedule content to play from USB. Your Philips professional display will wake from standby to play the content you want, and then return to standby once playback has finished.

Powered by Android

With Android on your professional display you'll enjoy a faster, richer and guest-friendly interface. It's your launch control to a wealth of dedicated hospitality services, applications and so much more. There's an easy-to-navigate menu with direct links to your favourite apps.

Discover Android

Integrated HTML5 browser

Connect and control your content over the internet with the integrated HTML5 browser. Using the Chromium-based browser, design your content online and connect a single display or your complete network. Show content in both landscape and portrait mode, with full-HD resolution. Streaming content can also be shown in a PIP (picture-in-picture) window. Simply connect the display to the internet using WiFi or with an RJ45 cable, and enjoy your own created playlist

Ultimate attention

Q-Line makes your content the focal point in any space.

Technical Specifications

Picture/Display

Diagonal screen size (inch)	85.6
Diagonal screen size (metric)	217.4
Panel resolution	3840 x 2160
Optimum resolution	3840 x 2160 @ 60 Hz
Brightness	400
Contrast ratio (typical)	1200:1
Dynamic contrast ratio	500,000:1
Response time (typical)	8
Aspect ratio	16:9
Viewing angle (horizontal)	178
Viewing angle (vertical)	178
Pixel pitch	0.4935 x 0.4935 mm
Display colors	1.07 Billion
Picture enhancement	3/2 - 2/2 motion pull down
	3D Combfilter
	Motion compens. deinterlacing
	Progressive scan
	3D MA deinterlacing
	Dynamic contrast enhancement
Panel technology	IPS
Clinical image	D-Image preset (dicom part 14 compatible)
Operating system	Android 8.0

Supported Display Resolution

Computer formats	1920 x 1080, 60Hz
	1680 x 1050, 60Hz
	1600 x 1200, 60Hz
	1440 x 900, 60Hz
	1280 x 1024, 60Hz
	1280 x 800, 60Hz
	1280 x 720, 60Hz
	1152 x 870, 75Hz
	1024 x 768, 60, 70, 75Hz
	800 x 600, 56, 60, 72, 75Hz
	720 x 400, 70Hz
	640 x 480, 60, 67, 72, 75Hz
	1152 x 864, 75Hz
	832 x 624, 75Hz
Video formats	3840 x 2160, 60Hz
	3840 x 2160, 30Hz
	576p, 50Hz
	576i, 50Hz
	480p, 60Hz
	480i, 60Hz
	1080p, 50, 60Hz
	1080i, 50, 60Hz
	720p, 50,60 Hz

Connectivity

Video input	DVI-D (x1)
	HDMI 2.0 (x3)
	USB 2.0 (x2)
	VGA (Analog D-Sub) (x1)
Audio input	3.5 mm jack
Audio output	3.5mm jack
External control	RS232C (in/out) 2.5 mm jack
	IR (in/out) 3.5 mm jack
	RJ45
Other connections	OPS

Convenience

Keyboard control	Hidden
	Lockable
Network controllable	RS232
	RJ45
Signal loop through	RS232
	IR Loopthrough
Energy saving functions	Smart Power
Remote control signal	Lockable
Tiled Matrix	Up to 15 x 15
Placement	Landscape (18/7)
	Portrait (18/7)
Start-up	Switch on delay
	Switch on status
	Boot on source
Start-up window	enable / disable Philips logo
Ease of installation	Smart Insert

Dimensions

Bezel width	15.5 mm (Even bezel)
Set Width	1929.0
Set Height	1100.0
Set Depth	69.5mm(D@wall mount) / 91.8mm(D@handle)
Set Width (inch)	75.94
Set Height (inch)	43.31
Set Depth (inch)	2.74(@ wall mount)/ 3.61(@ handle)
Product weight	49.5
Product weight (lb)	109.13
Wall Mount	600 x 400 mm, M8

Operating conditions

Altitude	0 ~ 3000 m
Temperature range (operation)	0 ~ 40
Temperature range (storage)	-20 ~ 60
MTBF	30,000
Humidity range (operation)[RH]	20 ~ 80% RH (No condensation)
Humidity range (storage) [RH]	5 ~ 95% RH (No condensation)

Power

Mains power	100 - 240V~, 50/60Hz
Standby power consumption	<0.5W
Power Saving Features	Smart Power
Consumption (Max)	480 W
Consumption (Typical)	320
Energy Label Class	G

Sound

Built-in speakers	2 x 10W RMS

Accessories

Included accessories	AC Power Cord
	RS232 cable
	Remote Control
	Batteries for remote control
	Quick start guide
Included Accessories	IR sensor cable (1.8 m) (x1)
	RS232 daisy-chain cable
	M3 screw (X1)
	M4 Screw (x1)
	Philips logo (x1)
	USB Cover (x1)

Multimedia Applications

USB Playback Video	MPEG
	H.264
	H.263
	H.265
USB Playback Picture	BMP
	JPEG
	PNG
USB Playback Audio	AAC
	HEAAC
	MPEG

Miscellaneous

Warranty	3 year warranty
On-Screen Display Languages	Simplified Chinese
	Traditional Chinese
	English
	French
	German
	Italian
	Polish
	Russian
	Spanish
	Turkish
	Japanese
	Arabic
Regulatory approvals	CE
	CB
	BSMI
	CU
	ETL
	FCC, Class A
	PSB
	VCCI
